PARTS LIST
To order replacement parts: provide your customer service representative with the product model
number and the part number located on the Parts List below, along with the quantity you require.
NO DESCRIPTION QTY NO DESCRIPTION QTY
A Carriage bolt 2 23 Alloy bushing 2
B Arc washer 5 24 Flat washer 2
C Acorn nut 2 25L/R Pedal 1pr
D Allen bolt 3 26 Nut cap 4
E Nylon nut 7 27 Plastic bushing 6
F Flat washer 4 28 Shaft 1
G Hex bolt 2 29 Spring washer 2
H Flat washer 5 30 Axle 1
I Flat washer 2 31 Hex nut 2
1 Main frame 1 33 Hex nut 1
2 Front stabilizer 1 34 Washer 1
3 Rear stabilizer 1 35 Two-slot nut 1
4L/R Handlebar 1pr 36 Collar housing 2
5L/R Connecting arm 1pr 37 Collar ball 2
6 L-shape pin 1 38 Tri-slot nut 1
7 Seat post 1 39 Washer 1
8 Round ring 1 40L/R Post 1pr
9 Saddle 1 41 Tension spring 1
10 Leveling cap 2 42 Cross tapping screw 2
11 Foot pad 2 43 Bracing wire cover 1
12 Friction belt 1 44 Cross tapping screw 1
13 Seat post bushing 1 45 Screw 2
14 Tension controller 1 46 Chain 1
15 Foam grip 2 47 Chain wheel 1
16 Pedal shaft 2 48 Cross tapping screw 4
17 Water bottle holder 1 49 Flat washer 4
18 Alloy bushing 2 50a/b Chain cover 1pr
19 Crank 1 51 Crank sealing 1
20L/R Nylon nut 1pr 52 Flange nut 2
21 Water bottle 1 53 Adjusting bolt 2
22 Cross screw 2 54 Fan wheel 1
To Next Page
