HG-CF-1129 Rev. F - 19.10.09
Page 4
FLUID CONNECTIONS CAPACITY MAX SOLIDS MAX DISCHARGE HEAD DISPLACEMENT/STROKE
1/2” / 3/4” TRI-CLAMP SIZE
Other options available
0 - 18 Litres/Minute
(0 - 3.9 Gallons/Minute)
1 MM
(1/16”)
88 Meters
(289 ft)
0.015 Litres
(0.003 UK Gallons)
MAX. WORKING PRESSURE AIR INLET TEMPERATURE LIMITS PUMP WEIGHTS :-
8.6 Bar (125 psi) 1/4” BSP (F) Determined by Elastomers SS :- 4.0 Kg
TECHNICAL DATA
Caution - Operating temperature limitations are as follows:
Operating Temperatures
Materials
Maximum Minimum Optimum
Virgin PTFE - Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
PTFE : molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine
trifluoride or oxygen difluoride which readily liberate free fluorine at elevated temperatures.
356
o
F
180
o
C
32
o
F
0
o
C
50
o
to 212
o
F
10
o
to 100
o
C
LAMBERT ROAD,ARMSTRONG, WASHINGTON,
TYNE & WEAR NE37 1QP, ENGLAND.
TEL. : 0044 (0) 191 4177475
FAX. : 0044 (0) 191 4175435
Web Site : www.blagdonpump.com
E-Mail : sales@blagdonpump.com
IMPORTANT
This pump should be used in accordance with the requirements of the Health and Safety at Work Act 1974.
All business conducted subject to Blagdon Pump. Terms and Conditions of Sale, available on request.
TYPICAL CODE = B06. 04. S S. B B. T T S - P 1
WETTED COMPONENTS
S : 316L STAINLESS STEEL
NON - WETTED COMPONENTS
S : 316L STAINLESS STEEL
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
VALVE SEATS
S : 316L STAINLESS STEEL
VALVE BALLS
T : PTFE
S : 316 STAINLESS STEEL
DIAPHRAGMS
T : PTFE
O : ONE PIECE PTFE
DESIGN LEVEL
MODEL
B06 : STANDARD
X06 : ATEX CAT. 2
SUFFIX
P : BSP CONNECTIONS
P1: TRI-CLAMP CONNECTIONS
ELECTRO - POLISHED
