Operating Instruction 1-7D
Technical data
1.1 Rating
Unit / designation : ISPC Blastrac/EBE blast cleaning
machine
Machine type : 1-7D
Manufacturer : ISPC Blastrac/EBE
Utrechthaven 12
NL-3433PN Nieuwegein
THE NETHERLANDS
1.2 Unit specifications
Dimensions:
1-7D
Length 1040 mm
Width 310 mm
Height 980 mm
Weight 48 kg
Connected loads (electrical system):
The indicated input current values correspond to the nominal current
values of the motors working under full load. These values are not
achieved under normal operating conditions.
1-7D
Power
consumption
Input
current
Blast wheel drive 2,5 kW max. 16 A
Filter unit 3,0 kW max. 16 A
Electrical connection required : 230 V, 50 Hz, 16 A, plug 230V
