Blastrac 2-20DT - Page 24

24
Put in B21316-1.
M10x25 / heavy washer
/ spring lock washer.
Do not tighten yet.
Put the top liners in.
Make sure that the top
liners sit close to the
edges of the side
liners and center liner.
Tighten the bolt
at the back of the
blast housing.
