Blastrac 2-20DT - Page 25

25
Put in B21316-2.
This surface may
not stick out of
the body!
Tighten the bolt
at the back of the
blast housing.
M12x30 / washer
/ spring lock
washer.
Mount the blast
house covers back.
Tighten the pressbolts
carefully and tighten the
nut, so the top liners are
pressed against the side
liners and center liner.
Mount the blast
wheel cover plate.
(5x) M12 Hexagon
domed cap nut /
washer / spring lock
washer.
(2x) M12 x 30 bolt /
washer / spring lock
washer.
