Operating Instructions BMP-E165
Section 3 - General Information April 2006
©Blastrac April 2006
16
1
2
3
4
Fig. 3.1
1) Control panel
2) Dust Collector Connection
3) Depth Setting Adjustment Wheel
4) Machine Housing
