Operating Instructions BMP-E165
Section 6 – Operation February 2006
©Blastrac February 2006
29
6.3 Recommended Scarifying Direction
1. Place the dust collector near the site power connection and place the
scarifier near the dust collector.
2. Unroll the dust collector hose and connect one end to the scarifier and
the other end to the dust collector.
3. Start both machines. For further details, see Section 5
“Preparation/Starting”
4. The scarifier should be driven in a “back-and-forth” direction, away
from the dust collector, as depicted in Figure 6.1.
To avoid damage to the dust collector hose, be aware of the
hose length and do not drive the scarifier out of the hose’s
range.
5. Finish by moving the dust collector and scarifying that area where the
dust collector was stationed.
1
3
2
Fig 6.1
1) Dust Collector
2) Dust Hose
3) Scarifier
