Operating Instructions BMP-E165
Section 3 - General Information April 2006
©Blastrac April 2006
19
3.4 Scarifier Drum Details (cont’d)
1
2
3
4
5
1 Drum
2 Shaft
3 Shaft Retainer
4 Screw
5 Lockwasher
