Contact of the S switch
or the pull cord switch is
OPENED
Fan runs
Contact of the S switch
or the pull cord switch is
CLOSED
Fan does not run
L
LT
S
N
L
N
QF
L
LT
N
L
N
QF
Fan does not run
Contact of the S switch
or the pull cord switch is
CLOSED
Fan runs
Contact of the S switch
or the pull cord switch is
OPENED
Activation of turn-off
delay timer (2-30 minutes)
14.
15.
Bravo 100/125/150
Bravo 100/125/150 S
Bravo 100/125/150 T
Bravo 100/125/150 ST
