Blaupunkt Arrifana 08C User Manual

www.blaupunkt.com
Arrifana 08C
20
CLOCK BUTTON
1. To set the correct time of the day, press the CLOCK button.
2. The clock display will flash; set the clock using the UP/DOWN button.
3. Each time the UP or DOWN button is pressed the minute display will
increment/decrement by 1. After the correct time is set press the CLOCK button to store
the set time.
SLEEP FUNCTION
Under this function the unit maintains the room temperature and humidity at optimum level
with silent operation. The unit will run in a preset programmed algorithm which will vary the
set temperature after every preset time interval. The unit will be turned off after 8 hours and
will be in STANDBY mode.
Fan speed cannot be adjusted and is always set to low under this function.
TO SET
1. Select the desired mode of operation – Cool/Dry or SMART.
2. Press the SLEEP button, sleep icon will appear on the display and the remote which will
indicate the unit is set in SLEEP function.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
