Arrifana 08C
21
3. In SLEEP function if the unit is running in COOL mode, after each hour the set temperature
is increased by 1°C, this happens for the first two hours after which the unit will run at
(set temperature + 2°C) for remaining 6 hours before it is switched off.
4. In Dry mode the dehumidifying power of the appliance is partially reduced every hour for
the first two hours and then the unit will run for 6 hrs. at the reduced dehumidifying
power before it goes in STANDBY mode.
TIMER FUNCTION
Timer function is used to set the ON or OFF time of the unit.
This function can only be set using the remote control.
TIMER ON
This function is used to start the unit after a specific time interval.
To set the ON time:
1. Using the remote turn the unit ON and select the mode in which you want your unit to run
when the selected time interval is elapsed, example Cooling mode, 25°C fan speed high.
2. Press the ON/OFF button on the remote to switch the unit in STANDBY mode.
3. Press the TIMER button; the remote handset will come up with the time icon and ON next
to it.
4. Press the TIMER button once; the clock display will come up and continue to flash next to
the ON time icon.
5. Set the time after which you want the unit to be turned ON using the UP/DOWN button.
6. Once the selected time interval is set press the TIMER button again to store the time
interval in the memory.
7. The unit will start operating in the mode selected when the preset time is reached.
8. To cancel the timer setting, press the TIMER button.

Blaupunkt Arrifana 08C Specifications

General

Type	Monobloc mobile air conditioner
Noise level	55 dB
LED indicators	Yes
Number of speeds	3
Water tank capacity	1 L
Airflow (high speed)	350 m³/h
Cooling capacity (max)	8000 BTU/h
Air conditioner functions	Cooling, Dehumidifying, Ventilating
Cooling temperature range	18 - 32 °C
Cooling capacity in watts (max)	2330 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	-
Display type	LED
Product color	Grey, White
Current	4.1 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (cooling)	890 W
Energy efficiency class (cooling)	A
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	770 mm
Width	283 mm
Height	506 mm
Weight	25000 g
