GTA 470 DSP
47
Fig. 4
Fig. 5
REMOTESUPPLY
+
12V
GROUND
BRIDGE MODE
SPEAKERS
FRONT
REAR
FUSE
20A
20A
RL
min. 2 Ohm min. 2 Ohm
min. 2 Ohm min. 2 Ohm
REMOTESUPPLY
+
12V
GROUND
BRIDGE MODE
SPEAKERS
FRONT
REAR
FUSE
20A
20A
RL
min. 2 Ohm min. 2 Ohm
min. 2 x 2 Ohm
