GTA 470 DSP
48
Fig. 5a
Fig. 6
REMOTESUPPLY
+
12V
GROUND
BRIDGE MODE
SPEAKERS
FRONT
REAR
FUSE
20A
20A
RL
min. 2 x 2 Ohm
min. 2 x 2 Ohm
REMOTESUPPLY
+
12V
GROUND
BRIDGE MODE
SPEAKERS
FRONT
REAR
FUSE
20A
20A
RL
min. 4 Ohm
min. 4 Ohm
Anschluss • Connection • Raccordement • Conexión • Ligação • Collegamento • Podłączenie •
Připojení • Подключение • Racordare • Cвързване • Priključak • Priklop
