Operating instructions
Index, Inspection and servicing
102620 • 05/2019
1
Index
Component overview
1 Fundamental safety instructions ....... 1
1.1 Designated use ........................................ 1
1.2 Fundamental measures .......................... 1
1.3 Description of symbols and notes ........ 1
2 Transport and storage .......................... 2
2.1 Transport .................................................. 2
2.2 Storage ...................................................... 2
3 Mounting ................................................. 2
3.1 Mounting conditions ............................... 2
3.2 Compressed-air port ............................... 3
3.3 Electrical connection .............................. 3
4 Operation ................................................. 5
4.1 Safety instructions .................................. 5
4.2 Switching the unit on ............................. 5
4.3 Daily check-ups ....................................... 5
4.4 Switching the unit off ............................. 5
4.5 Original BLITZ accessories .................... 5
5 Inspection and servicing ..................... 6
5.1 Safety instructions .................................. 6
5.2 Checking and topping up the oil level . 7
5.3 Changing the oil ...................................... 7
5.4 Draining the condensation water ......... 8
5.5 Checking and changing the suction
filter cartridge .......................................... 8
5.6 Tighten the screw connections. ............ 8
6 Maintenance schedule ......................... 9
7 Trouble shooting ................................. 10
Technical annex
1 Fundamental safety instruc-
tions
1.1 Designated use
The compressor system is intended exclusive-
ly for the generation of compressed air. Any
other use shall be considered an undesignat-
ed use.
1.2 Fundamental measures
 Never point compressed air at persons.
 Observe these operating instructions.
 Keep these operating instructions availa-
ble at the location of use at all times.
 Observe the regular maintenance dead-
lines (cf. chapter 6 “Maintenance plan”).
 Use original BLITZ parts and approved
operating material only.
 Do not use compressed air for breathing
without corresponding treatment.
 Do not modify the system.
 Use mounting parts and devices down-
stream from the compressor which have
been designed for the maximum operating
overpressure of the compressor.
 In your capacity as proprietor, please en-
sure that all safety regulations are ob-
served by the operating staff.
 Do not use the compressor as a climbing
aid.
1.3 Description of symbols and
notes
Danger
Mortal danger and risk of injury.
Caution
Damage to property.
Information and tips.
