8
3. Push the quick release skewer through the axle of
the front wheel from the side opposite the brake
rotor disc.
4. Add the spring, with the small end of the spring
facing the bike, and the larger side of the spring
resting against the cap.
5. Install the cap, leaving just enough space for the
fork dropouts to be inserted.
6. Remove the plastic fork spacer from the fork.
7. Install the front wheel so that it is fully seated in
the front fork dropouts, and the brake rotor disc
slides into the brake caliper.
Tip: If you’re having trouble getting your front wheel
on, check to see that the brake cable is loose
enough.
Assembly
