43
d r i v e r o r i e n t a t i o n
Heater Filter Access
Heater Valve Lever
A red lever on the front heater housing to the left of the Driver’s foot area controls
the rate of heated fluid flowing through the heater unit, providing a “temperature
control” for the heater.
Heater FIlter Panel
The filters in the heater system must be maintained and changed on a regular basis,
to maintain the airflow across the heater cores. The main heater filter is located be-
hind a small panel at the driver’s left. This panel is held in place by luggage type over
the center clasps. To remove the filter, pull upward and outward. To replace the filter,
press it firmly into position and replace the cover panel. The cover panel must be in
place to maintain the airflow through the filter.
To Next Page
