Blue Seal SG 4 E2 - Overall Dimensions

8
Model A B C D E
(mm) (mm) (mm) (mm) (mm)
SG 4 E2 460 521 670 851 280
SG 45 E2 530 600 745 940 280
SG 5 EC2 600 600 810 1005 350
SD 5 EC2 600 600 810 1005 350
SD 5 EC BT2 600 600 810 1005 350
OVERALL DIMENSIONS
10
A
B
D
C
E
