Blue Seal SG 4 E2 - Troubleshooting

26
FAULT
The machine does not switch on.
Water does not ll
Insufcient washing.
Insufcient rinsing.
CAUSE
Main switch disconnected.
Water valve closed.
Drain hose lter dirty.
Rinse nozzles clogged.
Overow hose not inserted correctly
ALARM H2:
Water missing in tank
WARNING F1:
Door open
Wash nozzles clogged.
Wash lter dirty.
Wash spray arm blocked
Detergent insufcient or missing
Insufcient wash conditions
ALARM H3:
Wash temperature insufcient
ALARM A3:
Probe disconnected or interrupted
Rinse nozzles clogged.
Limestone obstruction in boiler.
Water pressure below 2 bar. - 200 Kpa
Insufcient temperature
Improper position of nozzles or nozzles
damaged
ALARM H1:
Rinse temperature insufcient
ALARM A3:
Probe disconnected or interrupted
ALARM A5:
Boiler does not heat
SOLUTION
Connect switch.
Open the valve.
Detach the drain hose (4 Fig.6/7) and clean the lter. Un-
screw and wash the nozzles (21 Fig. 9) in running water
Check that the overow hose is inserted properly (14
Fig. 9).
Check mains water supply;
Switch the machine off and back on
Check that the door is closed perfectly and/or Level/
check levelling of the machine
Clean the nozzles of the wash spray arms (18 Fig. 9).
Clean the lter (15 Fig. 9).
Remove and clean the spray arm (16 Fig. 9).
Restore the detergent in the tank and check its concen-
tration.
Check that the washing phase is carried out correctly.
Wait for the tank to reach running temperature and
perform a new cycle
Contact the Assistance Service.
Unscrew and wash the nozzles (18 Fig. 9) in running.
Contact the Assistance Service.
Wait for pressure to be restored or purchase a new
pressure pump.
Contact the Assistance Service
Check that the nozzles are in the correct position and
replace the damaged ones.
Wait for the boiler to reach running temperature.
Contact the Assistance Service.
Contact the Assistance Service.
Check that the drain pipes are clean
TROUBLESHOOTING
Part 2: Reserved for Operator
ENGLISH
