Blue Seal SG 4 E2 - Installation and Technical Diagrams; Drain Hose Connection; Water Connection; Electric Connection

28
Part 3: Reserved for technician
IMPORTANT
Any installation, electric or hydraulic connection,
programming, maintenance operation etc. must be
carried out by SUITABLE qualied personnel authori
sed by the manufacturer; operations carried out by
UNQUALIFIED personnel can jeopardise the safety
of the operator as well as other personnel (user, etc.)
or the system connected to the dishwasher.
The manufacturer will not be held liable for accidents to
persons or objects resulting from failure to comply
with the rules specied above.
3.1 INSTALLATION (Fig. 6)
- After having removed the packaging, make sure that
the machine is intact and that all the supplied parts are
present.
- Position the machine at its nal installation site and level
it by acting on the adjusting feet (20).
3.1.a Drain hose connection (Fig. 6)
- Connect the drain hose (11) to the overow trap and
the other end to the drain pump.
IMPORTANT
It is essential to make sure that the drain hose runs ush
along the oor and has no bottlenecks.
3.1.b Water connection (Fig. 6)
- Connect the supplied ller hose (4) to the solenoid
valve and the other end of the ller hose (4) to a 3/4"
G threaded valve and apply the lter (8).
ATTENTION
It is mandatory to connect the cold water supply hose
to a partialisation valve in order to separate the supply
system from the machine itself and to check that there
are no bottlenecks.
Wherever sand is found in the water supply circuit, a lter
must be applied between the water circuit and the machine.
If it has none, it is recommended to install a descaler
upstream of the machine with calibration min 4 max. 8
French degrees.
The manufacturer will not be held liable for damaged
to the machines resulting from failure to comply with
the rules specied above
ENGLISH
3.1.c Electric connection (Fig. 5)
PERICOLO
- Before performing the electrical connection, make
sure that the data on the power line correspond to
those indicated on the rating plate (pos. 3 Fig. 5) and
that the main electric power switch upstream of the
machine is disconnected “ O ” OFF.
- An ominpolar power switch, appropriately sized
with a minimum contact opening of 3 mm must be
installed between the power line and the machine.
- Connect the power cable (9) to the main switch
upstream of the machine.
- Connect the equipotential earth electrode to the
terminal (7).
- The power cable CANNOT be replaced by the user
but ONLY by technical assistance.
- There must be an efcient earthing system, com-
pliant with prevention standards in force, for the
safety of the operator and of the equipment.
- The power cable must not be pulled or crushed
during normal operation or routine maintenance.
- The equipotential terminal xed to the body must
be connected to an equipotential cable with a cross-
section suitable to the application.
- Respect the polarities of the wiring diagram.
- For further information, see the attached wiring
diagram.
The manufacturer will not be held liable for acci-
dents to persons or objects resulting from failure to
comply with the rules specied above.
