LEGENDA SCHEMI MACCHINE A CICLO
COMPONENT LEGEND FOR UNDERCOUNTER MACHINES
LEGENDA SCHEMA MACHINES A CYCLE
LEGENDE SCHEMA FÜR PROGRAMM-AUTOMATEN
LEGENDA ESQUEMAS MAQUINAS A CICLO
LgBFCG
File I L M N O P Q Pagina
LgBFCG.DOC 22/01/01 07/03/01 26/01/06 30/10/09 01/10/10 14/12/10 09/06/17
8/9
Y1s ELETTROVALVOLA ACQUASTOP ELECTROVANNE ACQUASTOP
WATER STOP SOLENOID VALVE MAGNETVENTIL FÜR WATER STOP
ELECTROVALVULA ACQUASTOP
Y2 ELETTROVALVOLA CARICO VASCA/RISCIACQUO ELECTROVANNE POUR CHARG.CUVE/RINÇAGE
TANK FILL/RINSE SOLENOID VALVE MAGNETVENTIL FÜR TANKFÜLLUNG/NACHSPÜLUNG
ELECTROVALVULA CARGA CUBA/ACLARADO
Y3 ELETTROVALVOLA CARICO VASCA SUPPLEMENTARE ELECTROVANNE ARRIVEE EAU CUVE
SUPPLEMENTARY WATER INLET TANK MAGNETVENTIL ZUSÄTZL.TANKFÜLLUNG
ELECTROVALVULA CARGA CUBA
Y4 ELETTROVALVOLA RIGENERAZIONE ELECTROVANNE REGENERATION
REGERATION SOLENOID VALVE MAGNETVENTIL FÜR REGENERIERUNG
ELECTROVALVULA REGENERACION
Y4A ELETTROVALVOLA RIGENERA ADDOLCITORE ELECTROVANNE RÉGÉNÉRATION ADOUCISSEUR
SOFTENER REGENERATION SOLENOID VALVE MAGNETVENTIL REGENERATION WASSERENTHÄRTER
ELECTROVALVULA REGENERACION DESCALCIFICADOR
Y5 ELETTROVALVOLA SCARICO ELECTROVANNE VIDANGE
DRAIN SOLENOID VALVE MAGNETVENTIL FÜR ABLAUF
ELECTROVALVULA DESAGUE
Y6 ELETTROVALVOLA RISCIACQUO SUPPLEMENTARE ELECTROVANNE RINÇAGE SUPPLEMENTAIRE
SUPPLEMENTARY RINSE SOLENOID VALVE MAGNETVENTIL FÜR ZUSÄTZLICHE NACHSPÜLUNG
ELECTROVALVULA ACLARADO SUPLEMENTARIO
Y8 ELETTROVALVOLA CARICO CILINDRO ELECTROVANNE REMPLISSAGE CYLINDRE
CYLINDER WATER INLET SOLENOID VALVE MAGNETVENTIL FÜR ZYLINDERWASSERZULAUF
ELECTROVALVULA CARGA CILINDRO
Y8a ELETTROVALVOLA DISCESA CAPOT ELECTROVANNE FERMETURE CAPOTE
LOWER HOOD SOLENOID VALVE MAGNETVENTIL FÜR HAUBEN SCHLIESSUNG
ELECTROVALVULA CIERRE CAMPANA
Y10 ELETTROVALVOLA RISCIACQUO OSMOSI ELECTROVANNE RINÇAGE OSMOSE
OSMOSIS RINSE SOLENOID VALVE MAGNETVENTIL FÜR OSMOSE-NACHSPÜLUNG
ELECTROVALVULA OSMOSI
Y11 ELETTROVALVOLA BREAK TANK ELECTROVANNE BREAK TANK
BREAK TANK SOLENOID VALVE MAGNETVENTIL FÜR BREAK TANK
ELECTROVALVULA BREAK TANK
Y12 ELETTROVALVOLA PRERISCIACQUO ELECTROVANNE PRE RINÇAGE
PRE RINSE SOLENOID VALVE MAGNETVENTIL FÜR VORNACHSPÜLUNG
ELECTROVALVULA PRE ACLARADO
Y13 ELETTROVALVOLA RISCIACQUO RIGENERE ELECTROVANNE RÉGÉNÉRATION (RINÇAGE RÉSINES)
REGENERATION SOLENOID VALVE (RESINS RINSE) REGENERIERUNGSMAGNETVENTILE (HARZE NACHSPÜL)
ELECTROVÁLVULA REGENERACION (ACLARADO RESINAS)
Y13A ELETTROVALVOLA SCARICO SALAMOIA ELECTROVANNE RÉGÉNÉRATION (VIDANGE)
REGENERATION SOLENOID VALVE (DRAIN) REGENERIERUNGSMAGNETVENTILE (SALZLÖSUNG ABLAUF)
ELECTROVÁLVULA REGENERACION (DESAGUE)
YV2 ELETTROVALVOLA VAPORE VASCA ELECTROVANNE VAPEUR CUVE
TANK STEAM SOLENOID VALVE DAMPFMAGNETVENTIL FÜR TANKHEIZUNG
ELECTROVALVULA VAPOR CUBA
YV3 ELETTROVALVOLA VAPORE BOILER ELECTROVANNE VAPEUR SURCHAUFFEUR
BOOSTER STEAM SOLENOID VALVE MAGNETVENTIL FÜR BOILERHEIZUNG
ELECTROVALVULA VAPOR BOILER
1C BREAK TANK BREAK TANK
BREAK TANK BREAK TANK
BREAK TANK
