BL6-U Parallel Integrated Controller Quick Commissioning User Manual
39
Time Setup Parameters List (Cont'd)
Para
No.
Display
Content
Range
Factory
Setting
Unit
Live
Change
F2-18
F2-19
Start Time1
System will automatically start the
elevator (Electric lock: ON) at set time.
00:00
…
23:59
00:00
Hour:
minute
Y
F2-20
F2-21
Stop Time1
System will automatically stop the
elevator (Electric lock: OFF) at set time.
This function is disabled if same
start/stop time.
00:00
…
23:59
00:00
Hour:
minute
Y
Note: The elevator automatic switch: F2-14, F2-15 F2-16, F2-17 were set separately as per hours
and minutes. Please follow the operator indication for this setting.
Input Type Setup Parameters List
Service Setup Parameters List
Para
No.
Display
Content
Range
Factory
Setting
Live
Change
F3-00
Input Type
Setting the input type on main control
panel. Each bit corresponds to one
terminal. Set default level of main board
input port. ON: Close enable, OFF: Open
enable.
0~
4294967295
3726441599
N
F3-01
Car Input Type
Setting the input type of cabin. Each bit
corresponds to one terminal.
ON: Close enable, OFF: Open enable.
0~
4294967295
4294967295
N
F3-02
Input select 1
X12 Input Function Selection
0~32
12
N
F3-03
Input select 2
X18 Input Function Selection
0~32
18
N
F3-04
Input select 3
X27 Input Function Selection
0~32
27
N
F3-05
Input select 4
X35 Input Function Selection
0~32
35
N
F3-06
Input select 5
Spare
0~32
25
N
F3-07
output select 1
Spare
0~32
0
N
F3-08
output select 2
Spare
0~32
11
N
F3-09
output select 3
Spare
0~32
12
N
Para
No.
Display
Content
Range
Factory
Setting
Live
Change
F4-00
Set Stop Floor1
Set elevator stop/bypass at floor
corresponds to each bit. (1-32 floors)
0~
4294967295
4294967295
Y
F4-01
Set Stop Floor2
Set elevator stop/bypass at floor
corresponds to each bit. (33-64floors)
0~
4294967295
4294967295
Y
F4-02
TIM Stop Floor1
Set elevator stop/bypass at floor
corresponds to each bit at the set time.
(1-32 floors)
0~
4294967295
0
Y
F4-03
TIM Stop Floor2
Set elevator stop/bypass at floor
corresponds to each bit at the set time.
(33-64 floor)
0~
4294967295
0
Y
F4-04
Door Select A1
Set elevator front door enable /disable at
floor corresponds to each bit (ON/OFF:
Front door enable /disable at this floor)
0~
4294967295
4294967295
(1~32
levels)
Y
F4-05
Door Select B1
Set elevator rear door enable /disable at
floor corresponds to each bit (ON/OFF:
Rear door enable /disable at this floor)
0~
4294967295
0
(1~32
levels)
Y
F4-06
Function Select
Set elevator functions enable /disable at
floor corresponds to each bit.
(ON: Enable, OFF: Disable)
0~
4294967295
0
Y
F4-07
Function Select 2
Set elevator functions enable /disable at
floor corresponds to each bit.
(ON: Enable, OFF: Disable)
0~
4294967295
0
Y
