BL6-U Parallel Integrated Controller Quick Commissioning User Manual
41
ON: Integrated controller LED has reverse display. This is used for Blue-light G-series cabinet in
room-less elevator (where control board is placed reversely)
OFF: Integrated controller LED has normal display. (U menu is reversed; F menu is normal)
ON: When ARD function is active, system will open brake for 1s (when sliding speed >0.1m/s, brake
will close again), it will then find the heavy load direction based on the sliding direction, use battery to
land the cabin on heavy load direction and reduce leveling energy cost.
ON: Enable elevator data recorder. Together with PC debugging software, after-sales/ service team can
provide fault diagnosis。
ON: open the releveling function;
OFF: turn off the releveling function. (control software 1000_5600 and the above version support this
function)
ON: open the door-open-in-advance function;
OFF: turn off the door-open-in-advance function. (control software 1000_5600 and the above version
support this function)
ON: open the door open waiting function for any floor. (control software 1000_5600 and the above
version support this function)
ON: enable the new national standard function;
OFF: the old national standard scheme is enabled. (control software 1000_5600 and the above version
support this function)
ON: If car speed inside leveling zone is still faster than rescue speed, then the car will be forced to stop
in leveling zone.
ON: Enable clearing car calls when no light curtain actions within three car-call stops in auto running
mode to anti trouble make.
ON: Enable auto-restricting-door function to prevent door lock loop disconnect caused by no
self-locking power.
OFF: Improve car stop; (Default)
ON: Give up the time-dependent decreasing speed curve after speed change in leveling zone.
ON: In UPS running mode, elevator will arrive in leveling zone, open the door, and close the Y23
contactor in 30s, then cut-off the UPS circuit to avoid UPS battery pack deep discharge.
ON: The car waits at homing floor with door open.
ON: Enable elevator run to bottom level in UPS running mode. (When applying this function, F4-07-00
and F4-07-25 will be no effect.)
ON: Enable TIM Stop Floor function.
Stop floor time set1 Start time: F2-18 & 19; End time: F2-20 & 21
TIM stop floor time set1 corresponds Set Stop Floor parameter is: F4-00 Set Stop Floor1, F4-01 Set
Stop Floor2.
Stop floor time set2 Start time: F2-14&15; End time: F2-16 & 17(multiplexing start time/stop time
setting).
TIM stop floor time set2 corresponds Set Stop Floor parameter is: F4-02 Set Stop Floor1, F4-03 Set
Stop Floor2.
ON: There is only one door zone signal, the elevator will still level while it turns from inspection to
auto or from error to normal or runs in ARD mode. It will avoid that the car door vane cannot drive the
hall door when it is too short.
ON: enable hall door and call door short connection detection function;
OFF: close this function. (control software 1000_5600 and the above version support this function)
ON: Elevator return to homing floor to proof reading level number when power on for the first time.
