CHART 2.1 Control Circuit Port definition and Function ()
Port
No.
Terminal
Symbol
Location
Definition
Usage
Interface Tech Spec
Interface
Type
Rated
Capacity
On/off
Time
Max
Speed
J5
I4
J5-5
Full Collective/Simplex Collective
Car call input 4/ Car call input 4
Input
Output
Input:
Optical-couple
Output: OC
Input:
DC 24V
7mA
Output:
300mA
Input:
10mS
Input:
100Hz
I5
J5-6
Full Collective/Simplex Collective
Car call input 5/ Car call input 5
I6
J5-7
Full Collective/Simplex Collective
Car call input 6/ Car call input 6
I7
J5-8
Full Collective/Simplex Collective
Car call input 7/ Car call input 7
I8
J5-9
Full Collective/Simplex Collective
Call up input 1/ Car call input 8
I9
J5-10
Full Collective/Simplex Collective
Call up input 2/ Car call input 9
J6
I10
J6-1
Full Collective/Simplex Collective
Call up input 3/ Call input 1
Input
Output
Input:
Optical-couple
Output: OC
Input:
DC 24V
7mA
Output:
300mA
Input:
10mS
Input:
100Hz
I11
J6-2
Full Collective/Simplex Collective
Call up input 4/ Call input 2
I12
J6-3
Full Collective/Simplex Collective
Call up input 5/ Call input 3
I13
J6-4
Full Collective/Simplex Collective
Call up input 6/ Call input 4
I14
J6-5
Full Collective/Simplex Collective
Call down input 2/ Call input 5
I15
J6-6
Full Collective/Simplex Collective
Call down input 3/ Call input 6
I16
J6-7
Full Collective/Simplex Collective
Call down input 4/ Call input 7
I17
J6-8
Full Collective/Simplex Collective
Call down input 5/ Call input 8
I18
J6-9
Full Collective/Simplex Collective
Call down input 6/ Call input 9
I19
J6-10
Full Collective/Simplex Collective
Call down input 7/ Call input 10
J7
X0
J7-8
SJX Inspection/auto input
X1
J7-7
SSXW up limit input
X2
J7-6
SXXW down limit input
X3
J1-5
SSMQ up leveling input
X4
J1-4
SXMQ down leveling input
X5
J1-3
SKDY auxiliary contactor input
X6
J1-2
KBC brake contactor feedback
X7
J1-1
Door open limit 2 input
J8
X8
J8-8
Door close limit 2 input
X9
J8-7
Safe plates 2 input
X10
J8-6
SJT Emergency stop input
X11
J8-5
SMB door inter-lock input
X12
J8-4
Left brake feedback input
X13
J8-3
SXF fire input
X14
J8-2
SMS jog up input (Attendant up)
X15
J8-1
SMX jog down input (Attendant
down)
