BL6-U Parallel Integrated Controller Quick Commissioning User Manual
8
3 PG Card Terminals & Assemblage
Note: With the hardware version upgrade, the corresponding pictures may be changed. Reference to
prevail in kind.
3.1 PG_V6
PG_V6 interface card is sync/async machine universal pulse encoder speed feedback and
frequency dividing output card.
PG_V6 is in supporting use of 5V line driver output type encoder. Encoder for async machine:
A/B, and encoder for sync machine: A/B/Z/U/V/W.
FIGURE 3.1 PG_V6 CARD
FIGURE 3.1 PG-V6 Card Port definition and Function
Freq dividing
signal OC output A
Freq dividing
signal OC output B
