7. Charging
AC200L supports five charging methods: AC, solar, car, generator,and Lead-acid battery.
Attention:
• Double-check that all cables are firmly plugged in.
• Avoid getting the plug and socket wet to prevent any potential damage.
7.1 AC Charging
Plug the AC200L into a standard wall outlet and start charging. Once it's fully charged, the
AC200L automatically stops charging to prevent overcharging. For a fast charge, you can
enable Turbo Charging in the BLUETTI App, which allows for an 80% capacity in just 45
minutes at an ambient temperature of 25°C (77°F).
7.2 Solar Charging
Connect the solar panels (in series) to AC200L via the DC input cable and solar charging
cable. When solar panels maintain a power output of 1,200W, the AC200L can be charged
up to 100% in about 2.4 hours. However, please be aware that the charging time may vary
based on weather conditions, sunlight intensity, panel orientation, and other variables.
Note:
• Make sure your solar panels meet the following requirements:
Voc: 12V-145V Current: 15A Max. Power: 1,200W Max.
• Non-waterproof solar panels will lose efficiency if they get exposed in the rain for a
long time.
