Chapter 7 System Specifications
BV5000-1350 BV5000-2250
Sonar
Sonar Head Field-of-View
1⁰x45⁰ 1⁰x45⁰
Pan Scan Angle Coverage
45⁰ - 360⁰ 45⁰ - 360⁰
Tilt Scan Angle Coverage
-65⁰ - 65⁰ -65⁰ - 65⁰
Update Rate Up to 40 Hz Up to 40 Hz
Frequency 1.35 MHz 2.25 MHz
Maximum Range 27m (90 ft.) 9m (30 ft.)
Number of Beams 256 256
Beam Width
1⁰ x 1⁰ 1⁰ x 1⁰
Beam Spacing
0.18⁰ 0.18⁰
Time Resolution 1.23 in 0.74 in
Mechanical
Size (L x W x H) 10.5(L) x 9.2(W) x 15.4(H) 8.9(L) x 8.6(W) x 15.4(H)
Weight in Air 21.7 lbs 19.1 lbs
Weight in Water 8.2 lbs 6.0 lbs
Depth Rating 300 m (1,000 ft.) 300 m (1,000 ft.)
Electrical
Power Consumption 45 W 45 W
SPT Junction Box 120-240 VDC 120-240 VDC
Voltage Directly to Head (if SPT
box not used)
12-48 VDC 12-48 VDC
Voltage Directly to Pan & Tilt (if
SPT box not used)
20-29 VDC 20-29 VDC
Communications
Required Com Channels Ethernet and RS485 Ethernet and RS485
Ethernet Bandwidth 50 Mbs 50 Mbs
Sonar IP Address 192.168.1.45 192.168.1.45
RS485 Settings
9600 baud, 8 data bits, Parity
None, 1 Stop Bit, No Flow
Control
9600 baud, 8 data bits, Parity
None, 1 Stop Bit, No Flow
Control
File Output Types
Data Output Formats .son, .off and .xyz files .son, .off and .xyz files
Data Output Units meters meters
