AVENTOS HF Stops
 Opening Angle Stop for HK-S Aventos, 75° restricted opening – 20K7A11
 Opening Angle Stop for HK-S Aventos, 100° restricted opening –
20K7A41
Place the opening angle stop under
the linkage pin with the square end
facing down the arm.
Clip the hooks underneath the square
end of the opening angle stop down over
the plastic linkage to lock into position.
