BLUM SERVO-DRIVE User Manual

26
SERVO-D RIVE
Instruction leaet
Supply voltage: ..................................................................................................................... 24.0 V DC
Rated current: ................................................................................................................................ 2.0 A
Power consumption in standby mode: ............................................................... ≤ 0.55 W (front closed)
Operating mode: .............................................................................. S3 5 % (max. 10 motions/10 min.)
Emission sound pressure level: ............................................................................................ < 70 dB(A)
Ambient conditions:
Transport / Storage: ......................................................................... -30 to +70 °C / 0 to 90 % r.H.
Operation: ................................................................. 0 to +40 °C / 5 to 80 % r.H. non condensing
Maximum altitude: ................................................... 2000 m (at an ambient temperature of 25 °C)
Protection category: ........................................................................................................................ IP20
Radio equipment:
Frequency band: .............................................................................................. 2.404 to 2.452 GHz
Maximum radio-frequency power: ....................................................................... +4 dBm / 2.5 mW
Range: ........................................ ................... typically 10 m (depending on material and contents)
Transmission method: ...................................................................... bidirectional, via a coded wire
Supply voltage: ..................................................................................................................... 24.0 V DC
Rated current: ................................................................................................................................ 2.0 A
Power consumption in standby mode (23.A001): .............................................. ≤ 0.15 W (front closed)
Power consumption in standby mode (23KA001): ............................................ ≤ 0.40 W (front closed)
Operating mode: .............................................................................. S3 5 % (max. 10 motions/10 min.)
Emission sound pressure level: ............................................................................................ < 70 dB(A)
Ambient conditions:
Transport / Storage: ......................................................................... -30 to +70 °C / 0 to 90 % r.H.
Operation: ................................................................. 0 to +40 °C / 5 to 80 % r.H. non condensing
Maximum altitude: ................................................... 4000 m (at an ambient temperature of 25 °C)
Protection category: ........................................................................................................................ IP20
Radio equipment:
Frequency band: .............................................................................................. 2.404 to 2.452 GHz
Maximum radio-frequency power: ....................................................................... +4 dBm / 2.5 mW
Range: ........................................................... typically 10 m (depending on material and contents)
Transmission method: ......................... ................... .......................... bidirectional, via a coded wire
SERVO-DRIVE drive unit for AVENTOS 21FA001, 21SA001, 21LA001, 21KA001
SERVO-DRIVE drive unit for AVENTOS top 23.A001, 23KA001
