BLUM TC Series User Manual

System overview
12  by Blum-Novotest 2012
Max.deflection X/Y:
Stylus length
(mm)
Max. deflection X/Y (mm)
TC60 TC61 TC62
TC62 LF
TC62 T TC63-10/TC76
TC63-30/TC76
TC64-10
TC64-10 T
30 14 14 7 6 12
50 19 19 11 9 17
75 26 26 16 13 24
100 32 32 20 17 30
150 44 45
200 57 58
Tab. 2.5
Measuring force X/Y:
Stylus
length
(mm)
Measuring force X/Y (N)
TC60 TC61 TC62 TC63-10/TC76
TC63-30/TC76
TC64-10
30 2,3 1,3
50 2,0 1,5 1,5 0,9
75 1,1 0,7
100 1,4 1,2 0,8 0,5
150 1,0 0,9
200 0,8 0,7
Tab. 2.6
