Systemoverview
V2A|04/2018
12
©byBlum‐Novotest
Tab.3‐7MeasuringforceX/Y‐LF(LowForce)
3.6 Completesystem
Fig.3‐2
IC56/IC57:
•SwitchON/OFFviaIRflash
•SignaltransmissionforTCseries
•TouchprobeTCandtoolsettingprobeIRcanalternativelybeprogrammedtoTCorDUO.
MeasuringforceX/Y‐LF[N]
Styluslength[mm] TC52LF TC53‐10/TC76‐LF
TC53‐30/TC76‐LF
TC54‐10LF
30 0.65 0.4
50 0.44 0.3
75 0.31 0.2
100 0.24 0.17
InstallationinstructionsIC56
InstallationinstructionsIF59
