BLUM TC76 - Page 14

Mountingandcommissioning
V2A|04/2018
14
©byBlum‐Novotest
Furtherrecommendations:
Tab.4‐4
NOTICE
Damagetothemeasuringsystembyfaultyoperationpossible.
 Checkthecorrectpositionofthegasketinsidethebatterycompartment.
 Keepthebatterycompartmentabsolutelycleananddry.
 Slightlygreasesealingfaceofthelidbeforeinsertingit.
Fig.4‐1
Type½AA,3.6V mAh
TadiranTL‐4902 1200
XenoXL‐050F 1200
OmniCellER‐14250 1200
VitzrocellSB‐AA02 1200
Disposebatteriesaccordingtolegalregulations.
11
5
10
3,6 V
(5) Battery
(10) Gasket
(11) Batterycompartmentlid
