BLUM TC76 User Manual

Mountingandcommissioning
©byBlum‐Novotest
21
V2A|04/2018
4.5 Cra nkedstyli
NOTICE
Damageofthemeasuringsystemduetomisuseispossible.
 Payattentiontotheareaofoperationandthemaximumovertr avel.
Fig.4‐6
Z+measurement:max.overtravel
SOvertravel
Z+measurement:areaofoperation Cmeasurement:areaofoperation
Z
Z+
R
P
Y
X
0,0
1,0
2,0
3,0
4,0
5,0
6,0
7,0
15 20 25 30 35 40 45 50 55 60 65 70
[mm]
P[mm]
R22
R30
R40
S
0
10
20
30
40
50
20 30 40 50 60 70 80 90 100
P [mm]
R
[mm]
0
10
20
30
40
50
16,5 50
R
[mm]
P [mm]
