Mountingandcommissioning
©byBlum‐Novotest
15
322000010S|V1B|07/2017
4.3 Pre‐assemblingprobecontact
NOTICE
Damagetothepredeterminedbreakingpointbyimpropermountingpossible.
Mountingprobecontact‐Adapterwithpredeterminedbreakingpoint:
Lockwithaflatwrenchonspannerflat(M
d
=0.5Nm).
Thepredeterminedbreakingpointmaynotbedamagedduringmounting.
Fig.4‐8
10
8
C
7
D
(7) Probecontact
(8) Adapterwithpredeterminedbreak‐
ingpoint
(10) Predeterminedbreakingpoint
(C) Flatwrench6mm
(D) Allenkey1.5mm
