AMF41W QUICK REFERENCE GUIDE
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
Specifications
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate. For wall mounted installations, height may exceed 2m.
Package Contents
• Video Input Connectors: 4 x HDMI Type A, 19-pin, female
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female
• Audio Output Connectors: 1 x 3.5mm stereo jack (2ch analogue audio)
• RS-232 Serial Port: 1 x 4-pin Phoenix connector
• TCP/IP Control: 1 x RJ45, female
• USB Connector (reserved): 1 x USB Type A, female
• WiFi Antenna Connections: 2 x SMA, female
• WiFi Specification for Europe only:
2.4GHz EIRP < 20dBm
5.150~5.250GHz EIRP < 23dBm
5.725~5.850GHz EIRP < 13.98dBm
• Dimensions (W x H x D): 215mm x 25mm x 141mm
• Shipping Weight: 1.5Kg
• Operating Temperature: 0°C to 45°C (32°F to +113°F)
• Storage Temperature: -20°C to 70°C (-4°F to +158°F)
• Power Supply: Class 1 802.3af PoE PD or 12V/2A DC
• 1 x AMF41W
• 1 x 4-pin Phoenix Connector (RS-232)
• 2 x Antenna
• 1 x Mounting Kit
• 4 x M2.5*5mm screws
• 1 x Quick Reference Guide
• 1 x 12V/2A DC Power Supply
Power Supply Specification
Model: NBS24J120200D5
Rated Input: 100-240VAC, 50/60Hz, 0.6A
Rated Output: 12VDC, 2.0A
Includes: US changeable plug, EU changeable plug, AU
changeable plug, UK changeable plug
Manufacturer: Shenzhen Mass Power Electronic Limited
Address: 437#, Hedong Village, Hengkeng Community,
GuanlanStreet, Bao’an District, 518110 Shenzhen, P. R. China
Please read the entire manual
carefully before operating this device.
RS-232 Configuration
The RS-232 port is used for control of source or display from the AMF41W. The default RS-232 communication settings are:
Baud Rate: 57600 Data Bit: 8
Stop Bit: 1 Parity Bit: none
06
