EX40B-KIT USER MANUAL
08
www.blustream.co.uk
Example Schematic
EX40B-Kit
Cat 5/5e/6
IR Cable
HDMI
DISPLAY
40m max
HDMI
IR
A
B
A
B
Link HDMI Output Power
DC
5V
IR RX
CAT
Input
Link IR TX
Link HDMI Input
0
1
1 0
Power
DC
5V
IR RX
Link
IR TX
CAT
Output
1 SOURCE
