HMXL88ARC USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk14
CEC Page - User-defined
The CEC User-defined Page allows you to send custom CEC commands to any Output in the matrix.
You can select an output and then enter the custom CEC command to send the desired function to the output display.
Note CEC is subject to the support of the sources and displays connected to the matrix.
RS-232 Page - Local
The RS-232 Page allows you to send commands either out of the local RS-232 port on the matrix itself, or via HDBT and
out of a compatible HDBT Receiver connected to a display. If the Local radio box is selected, RS-232 commands will be
sent out of the DB9 serial port at the rear of the matrix to a connected device. Baud rate and terminator command as
well as Hex or ASCII can be selected.
Sending an RS-232 command out via the Matrix can be useful in assisting with debugging and fault finding an RS-232
device connected to the matrix.
