ME-GO SERIES SLIDING GATE OPENER USER MANUAL
—
1
—
CONTETNS
PRODUCT SPECIFICATIONS
SAFETY GUIDELINES
MACHINE INFORMATION
PACKAGE CONTENTS
INSTALLATION PROCEDURE
Pre-Installation Steps
Main Engine Installation
Rack Installation
Magnet Placement
Electrical Connections
Infrared Sensor Wiring
Remote Control Operation
MAINTENANCE
FAQ & TROUBLE SHOOTING
WARRANTY
PRODUCT SPECIFICATIONS
Model No.
MD370
MD550
MD750
MD1200
Motor Power
370W
550W
750W
1200W
Max. Lifting Weight
1800 LB
2700 LB
4000 LB
5300 LB
Horse Power
0.5HP
0.75HP
1HP
1.6HP
Output Torque
18 N.m
26 N.m
35 N.m
45 N.m
Package Weight
43.7 lb
47.4 lb
48.3 lb
52.5 lb
Rated Voltage
AC 110V, 50/60Hz
Motor Speed
1400 rpm
Max. Gate Length
40ft (12m)
Work Duty
S2, 15 minutes
Gate Moving Speed
39.4 ft/min (12m/min)
Remote Control Range
100ft (30m)
Recording of Remotes
40pcs (2 are included)
Working Temperature
-77°F ~ 131°F
1
2
2-3
4
5-13
5
5-6
6-7
7-9
10-12
12
12-13
13
14-16
17
