Auto CPAP / CPAP System User Manual V1.0
5 / 51
5. Specifications
Device Size
Dimensions (L x W x H): 265 mm × 145 mm × 114 mm
Weight: 1.7 kg
Water capacity:
To maximum fill line 360 mL
Product Use, Transport and Storage
Operation Transport and Storage
Temperature: 5°C to 35°C (41˚F to 95˚F) -25°C to 70°C (-13˚F to 158˚F)
Humidity: 15% to 93% Non-condensing 15% to 93% Non-condensing
Atmospheric Pressure: 760 ～ 1060 hPa 760 ～ 1060 hPa
Heated Humidifier
Humidifier Settings: off, Auto, 1 to 5 (95˚F to 154.4˚F / 35°C to 68°C)
Humidifier Output: No less than 15 mg H
2
O/L
Environmental Conditions: Maximum airflow, 35°C, 15% relative humidity
Maximum Operating Pressure: 40 hPa
Pressure Drop with Humidifier: < 0.4 hPa at 60 LPM flow
Maximum Delivered Gas Temperature: ≤ 43°C
Cellular Module
Receiver Frequency Band: 850/900/1800/1900MHz
FCCID：XMR201202M35
Max RF power output: 33.0 dBm
WiFi Kit
FCCID: AZY-HF-LPT200
Mode of Operation
Continuous
Work Mode
CPAP, AutoCPAP
SD Card
The SD card can record patient data and fault information
AC Power Consumption
100 - 240 V ～
, 50 / 60 Hz, 2.5 A Max
100 - 240 V ～, 50 / 60 Hz, 2A Max
Main device input
24V, 3.33A
Device offer to Heated Tubing Communications Port
24 V 18 W
