AREAS WHERE INJURY OR ENTRAPMENT CAN OCCUR
1. Gate Wheels (Pets at risk when lying at the gate)
2. Between the gate & the end stop
3. The gate, during the closing cycle
4. Between the gate & the catch bracket
5. Pinion Gear
6. Between the gate operator & the gate
7. Gate Rollers
8. The gate during opening cycle
TECHNICAL SPECIFICATIONS
Thrust 8000N
Motor RPM 3600RPM
Wattage 144W
Voltage 24Vdc
Current 6A
Max. gate weight 800kg
Max. gate length 8mtrs
Duty cycle 70%
Manoeuvre speed 16m/min
Operating temperature -20degC + 50degC
Max gate weight 800kgs - level ground
* This technical data is simply indicative
1
2
3
4
8
5 & 6
7
