11
USING YOUR BATTERYPLUS35
INPUT POWER SOURCES
The BatteryPlus35 may be powered from auxiliary, mains and solar input sources.
When multiple inputs are available to the BatteryPlus35, the BatteryPlus35 uses
power as specified in the tables below to provide the current to simultaneously
power caravan loads and charge the caravan battery.
Table 4: Input Power Sources to the BP35-PM
INPUT SOURCE TO BatteryPlus35 POWER SOURCE
AUX + Mains Mains
AUX + Solar AUX/Solar Blending
AUX + Mains + Solar Mains/Solar Blending
Mains + Solar Mains/Solar Blending
Table 5: Input Power Sources to the BP35-HA and BP35-SR
INPUT SOURCE to BatteryPlus35 POWER SOURCE
AUX + Mains Mains
AUX + Solar AUX/Solar Blending
AUX + Mains + Solar Mains
Mains + Solar Mains
Auxiliary
The auxiliary input is designed for use with 12V DC power sources. The voltage of
the DC power source connected to the auxiliary input must not exceed 14.8V.
Fuse protection is required at the auxiliary positive input. The rating on this
protective fuse must not exceed 30A
Mains
The BatteryPlus35 mains power cord can accept power from either a 110V or 240V
voltage outlet.
To prevent your car battery from discharging when the vehicle’s ignition is off, please
disconnect the auxiliary input to the BatteryPlus35 whenever the car is not running.
