22
SPECIFICATIONS
BP35-PM BP35-SR BP35-HA
Input Voltage Range 110-240V AC ± 10%, 50-60Hz
Input Surge < 40A (cold start)
Output Current 35A (Load + Battery Current)
Factory Set Voltage 13.65V (Float Voltage)
Output Ripple Voltage <150mV
Battery Current Limit max. 20A max. 20A max. 30A
Low Voltage Disconnect (Lead Acid) 10.5V ± 0.2V
Battery Connect after LVD (Lead Acid) 12.8V ± 0.2V
Low Voltage Disconnect (LiFePO
4
) 12.0V ± 0.2V
Battery Connect after LVD (LiFePO
4
) 13.8V ± 0.2V
Battery Drain <15mA (when in Storage Mode)
AC/DC Efficiency >83%
Cooling Fan Thermally Controlled
Solar Output Current 30A (nominal)
Solar Start Voltage 17.5V
Solar Input Voltage (after start-up) 15-25V
Ambient Temperature 0-50 °C
Communication Communication bus available
Weight 2kg
Standards
Safety: IEC60335-2-29, IEC62109-1
EMC: CISPR 14
Approvals: RCM
