Can I use a wired in-car monitor?
A wired 12VDC battery voltage indicator can be used with TrailSafe series if desired.
When I pull the pin, the LED displays flashing RED -ORANGE?
The pull pin internal contacts may have become corroded particularly by exposure to
salt water or dirt leading to the resistance building up which may cause the brakes to
not operate correctly or for as long as desired.
I have charged my house battery, but TrailSafe shows an RED LED.
If a large load is applied to the house battery, such as a fridge, the house battery
terminal voltage may drop below the minimum TrailSafe threshold (due to the
internal resistance of the house battery).
Switch off any loads and re-test.
I thought it was not a good idea to remove the pin?
This is a key feature of the device and by removing the pin to test the unit it checks
to ensure that the contacts inside the case are not corroded and capable of making
a suitable electrical connection including wiring to the brakes. It also checks the
battery is ready to function should an emergency happen.
SPECIFICATIONS
TRAILSAFE SPECIFICATIONS
System Voltage 12V Nominal (not suitable for 24V systems)
Electric Brake Load 18A max
Brake Light Load 8A max
Communications Bluetooth Low Energy (BLE 5.0)
Wired Monitor Current 30mA max
Battery Chemistry Compatibility LiFePO4/Lead Acid
Temperature -20°C to 60°C
IP rating IP67
Battery Nominal Capacity 70Ah – 300Ah
13
