INSTALLATION INSTRUCTIONS
MOUNTING LOCATION
Secure TrailSafe to the right hand side draw bar of the trailer (the driver’s side)
approximately 300mm from the tow ball hitch. Mount horizontally on top or side of
the draw bar.
MOUNTING METHOD
Mount on the arm of the trailer using the supplied mounting screw or similar. Only
one mounting point is required so that the unit can swivel in an emergency. Ensure
that it is secured tightly so that it does not vibrate loose.
MOUNTING ORIENTATION
The wires and mounting bolt should be pointing towards the rear i.e. away from the
tow vehicle so that the pull pin is facing towards the tow vehicle. The pull pin will
then be pulled out freely should the vehicle and trailer separate. The other end of the
pull pin cord is attached to the towing vehicle by a D-shackle or similar.
7
