If the service is due within 700
miles, SERVD! 3 and the re-
maining distance 4 are displayed
and counted down in steps of
100 miles. It is briefly displayed
following the Pre-Ride-Check.
When a service date
elapses without service,
the general warning light
lights up in yellow, appearing
together with the date and
mileage (kilometerage) display.
SERVD! or SERVT! is displayed
permanently.
NOTICE
If the service display appears
more than a month before the
service date, the current day's
date must be reset in the in-
strument cluster. This situa-
tion can occur if the battery was
disconnected.
Oil level indicator
The oil level display 1 provides
information on the oil level in the
engine. This display can only
be activated when the vehicle is
stopped.
The conditions required for using
the oil level display are as follows:
Engine at normal operating
temperature.
Engine idling for at least ten
seconds.
Side stand retracted.
The Scooter is standing up-
right.
The possible displays at loca-
tions 1 and 2 mean:
OILLVL OK: the oil level is cor-
rect.
OILLVL CHECK: check the oil
level during the next refueling
stop.
OILLVL -- -- --: no measure-
ment possible (above-mentioned
conditions not met).
If the oil level is too low,
the corresponding warning
symbol is displayed.
3
35
z
Displays
