Meaning of the operating
instructions:
Operating instruction 1: the left
end has been reached.
Operating instruction 2: you
can leaf to the right.
Operating instruction 3: you
can leaf down.
Operating instruction 4: you
can leaf to the left.
Operating instruction 5: the
right end has been reached.
Operating instructions in
submenus
In addition to the operating in-
structions in the main menu,
there are additional operating in-
structions in submenus.
Meaning of the operating
instructions:
Operating instruction 1: the
current display is in a hierar-
chical menu. One symbol indi-
cates a submenu level. 2 sym-
bols indicate 2 or more sub-
menu levels. The color of the
symbol changes depending on
whether it is possible to return
to the top.
Operating instruction 2: an-
other submenu level can be
called up.
Operating instruction 3: there
are more entries than can be
displayed.
Display Pure view
Rocker button MENU long
press up.
5
87
z
TFT display
