F48�General�Vehicle�Electronics
9.�Steering�Wheel�Heating
75
Index Explanation
1 Vibration�actuator
2 Fuse�in�the�power�distribution�box�in�the�passenger�compartment
3 Body�Domain�Controller�(BDC)
4 Fuse�in�the�Body�Domain�Controller
5 Multifunction�steering�wheel�buttons,�right
6 Horn�switch
7 Multifunction�steering�wheel�buttons,�left
8 Button,�steering�wheel�heating
9 Steering�column�switch�cluster�(SZL)
10 Steering�wheel�module
11 Heating�element�for�the�steering�wheel�heating
The�F48�receives�a�steering�wheel�heating�(SA�248)�as�optional�equipment.�The�steering�wheel
heating�is�only�available�in�conjunction�with�the�leather�sports�steering�wheel�(SA�255).
