Secure attachment
If a case wobbles or is difficult
to fit, it has to be adapted to the
gap between the top and bottom
holders.
Screws 1 inside the case allow
you to make this adjustment.
Topcase
with topcase
OA
Opening topcase
Turn the key to the OPEN pos-
ition in the topcase lock.
Push lock barrel 1 forward.
Lever 2 pops up.
7
83
z
Accessories
