G12�Driver�Assistance�Systems
8.�Lane�Departure�Warning
33
Index Explanation
1 Control�units�for�radar�sensor,�left�(RSL)�(side�radar�sensor
for�the�front�left�side�collision�warning)
2 Active�Cruise�Control�(ACC)
3 Control�units�for�radar�sensor,�right�(RSR)�(side�radar�sensor
for�the�front�right�side�collision�warning)
4 Electronic�Power�Steering�EPS
5 Fuse�for�power�distribution�box,�front�right
6 Electronic�transmission�control�(EGS)
7 Diagnostic�socket
8 CAN�terminator
9 Signal�unit�(LED)�in�right�mirror�glass
10 Body�Domain�Controller�(BDC)
11 CAN�terminator
12 Advanced�Crash�Safety�Module�(ACSM)
13 Blind�spot�detection,�right�(primary)
14 Blind�spot�detection,�left�(secondary)
15 Seat�belt�buckle�switch,�driver
16 Steering�column�switch�cluster�(SZL)
17 Driver's�door�lock�switch
18 Intelligent�Safety�button
19 Instrument�panel�(KOMBI)
20 Controller�CON
21 Head‐Up�Display�(HUD)
22 Switch�block�for�driver's�door
23 Central�information�display�(CID)
24 Head�Unit�High�2�(HU-H2)
25 Audio�control�panel
26 Control�unit�for�optional�equipment�system�(SAS)
27 Signal�unit�(LED)�in�left�mirror�glass
28 CAN�terminator
29 Rain-light-solar-condensation�sensor�(RLSBS)
30 KAFAS�stereo�camera
31 Dynamic�Stability�Control�(DSC)
32 Digital�Motor�Electronics�(DME)
33 KAFAS�stereo�camera�heating
