G12�Driver�Assistance�Systems
14.�Night�Vision
60
G12�Night�Vision�warning�ranges�(acute�warning)
Index Explanation
A Maximum�distance�for�early�warning�of�animals�about�160�m�(the�length
depends�on�the�driving�speed�and�the�size�of�the�animal�detected)
B Maximum�distance�for�acute�warning�of�animals�about�100�m�(the�length
depends�on�the�driving�speed�and�the�size�of�the�animal�detected)
1 Detection�range�of�the�Night�Vision�camera�(opening�angle�about�24°)
2 Acute�warning�range�when�an�animal�is�detected
3 Early�warning�range�(the�width�of�the�detection�range�depends�on�the
size�of�the�animal�and�how�it�is�moving)
Display�in�the�central�information�display�(CID)
The�pedestrian�or�animal�warning�is�effected�irrespective�of�the�representation�of�the�Night�Vision
camera�image�in�the�central�information�display�CID.
The�warning�is�no�longer�shown�on�the�central�information�display,�but�instead�only�appears�in�the
instrument�cluster�and�on�the�Head‐Up�Display.�If�the�Night�Vision�camera�image�is�active,�identified
pedestrians�and�animals�are�shown�in�yellow.
Night�Vision�camera�image�on�the�central�information�display�showing�detected�people
