BMW R 1250GS Adventure User Manual

NOTICE
The adjustment wheel can be
turned more easily if you press
the clutch lever forward when
doing so.
Four settings are available:
Position 1: smallest distance
between handlebar grip and
clutch lever
Position 4: largest distance
between handlebar grip and
clutch lever
with Option 719 milled part
package, Classic
OE
or
with Option 719 milled part
package, Storm
OE
or
with HP machined-parts pack-
age
OE
Turn the adjustment lever 1 to
the desired position.
Adjustment options:
From position A: smallest dis-
tance between handlebar grip
and clutch lever.
Five steps toward position B
to increase the distance be-
tween the handlebar grip and
the clutch lever.
Brakes
Adjust brake lever
WARNING
Adjusting the brake lever
while driving
Accident hazard
Only adjust the brake lever
when the motorcycle is
stationary.
Turn the adjustment wheel 1
into the desired position.
6
119
z Setting

BMW R 1250GS Adventure Specifications

General

Displacement	1, 254 cc
Front Suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Bore x Stroke	102.5 mm x 76 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Max Power	136 hp at 7, 750 rpm
Max Torque	143 Nm at 6, 250 rpm
Transmission	6-speed
Fuel Capacity	30 liters
Seat Height	890 / 910 mm (adjustable)
Curb Weight	268 kg
Rear Suspension	BMW Motorrad Paralever; cast aluminum single-sided swing arm with WAD strut (weight-related damping)
Fuel consumption	4.75 l/100 km
Fuel type	Premium unleaded
Front Brake	Dual 305 mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 276 mm, 2-piston floating caliper
ABS	BMW Motorrad Integral ABS
Length	2, 270 mm
Width	980 mm
Dry Weight	249 kg (549 lbs)
Clutch	Wet clutch with anti-hopping function, hydraulically actuated
Frame	Two-section frame
Engine Type	Air/liquid-cooled flat twin (Boxer)
